Operating Voltage

24VDC (12VDC~28VDC)

Standby Current

0mA

Alarm Current

≤30mA(equivalent resistance is 470Ω 1/2W)

Indicator

Red. Illuminates after alarm

Type of Initiating Part

Reusable

Resuming Mode

Manually resumed by a special key

Ingress Protection Rating

IP43

Environmental Temperature

-10°C ~ +50°C

Relative Humidity

≤95%, non condensing

Dimension (L×W×H)

87.1mm×87.1mm×58mm (with back box)

Mounting Hole Distance

60mm
